UM4717Q Union Semiconductor
Same model may have multiple batches, images only for reference.

UM4717Q

Part No UM4717Q
Manufacturer Union Semiconductor
Catalog Interface - Analog Switches, Multiplexers, Demultiplexers
Description IC SWITCH SPDT X 2 3.5OHM 10QFN
Datasheet
UM4717Q Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Integrated Circuits (ICs) - Interface - Analog Switches, Multiplexers, Demultiplexers
Mfr Union Semiconductor
Package Tape & Reel
Product Status Active
Switch Circuit SPDT
Number of Circuits 2
On-State Resistance (Max) 3.5Ohm
Channel-to-Channel Matching (ΔRon) 500mOhm
Voltage - Supply, Single (V+) 1.8V ~ 5.5V
Switch Time (Ton, Toff) (Max) 80ns, 40ns
-3db Bandwidth 300MHz
Current - Leakage (IS(off)) (Max) 500pA
Crosstalk -70dB @ 10MHz
Temperature Range - Operating -40°C ~ 85°C
Mounting Type Surface Mount
Package / Case 10-UFQFN
Supplier Device Package 10-QFN (1.8x1.4)
Standard Package 2 pcs
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 387676-UM4717Q
Ultra Librarian 3D Model Ultra Librarian UM4717Q CAD Model

Description

The 387676-UM4717Q is a 2-channel SPDT Analog Switch from Union Semiconductor.

  • Application: Analog signal switching
  • Package: Tape and reel
  • Maximum On-State Resistance: 3.5Ohm
  • -3db Bandwidth: 300MHz
  • Maximum Leakage Current: 500pA
  • Crosstalk: -70dB @ 10MHz
  • Channel-to-Channel Matching: 500mOhm
  • Supply Voltage: 1.8V to 5.5V
  • Temperature Range: -40°C to 85°C
  • Status: Active
