The NZ2520SD-45.000000MHZ is a crystal oscillator manufactured by NDK (Nihon Dempa Kogyo Co., Ltd.). The '45.000000MHZ' indicates that this oscillator operates at a frequency of 45 MHz. Crystal oscillators like the NZ2520SD series provide a stable and precise clock signal for electronic applications.

Applications

• Mobile Communication Devices: Commonly used in smartphones and other mobile devices for timing control.
• Wireless Communication Modules: Found in modules such as Wi-Fi, Bluetooth, and GPS.
• Networking Equipment: Used in routers, switches, and other networking devices for timing synchronization.
• Audio/Video Equipment: Incorporated into audio and video processing systems.
• Test and Measurement Equipment: Utilized in oscilloscopes, spectrum analyzers, and other measurement instruments.

Features

• Frequency: 45.000000 MHz nominal frequency.
• Package Size: 2.5 x 2.0 mm surface mount package for compact PCB designs.
• Stability: Provides excellent frequency stability over temperature variations.
• Low Jitter: Delivers a clean clock signal with low jitter for reliable performance.
• Low Power Consumption: Designed for low power consumption, ideal for battery-powered applications.
• RoHS Compliant: Compliant with RoHS directives, ensuring environmental friendliness.

Benefits

• Precise Timing: Provides accurate and stable timing, which is essential for proper system operation.
• Compact Size: Enables integration into small and space-constrained applications.
• Low Power: Reduces power consumption, increasing battery life in portable devices.
• High Reliability: Offers consistent performance under various operating conditions.
• Easy Integration: Simplified assembly process due to surface mount design.

Additional Details

The NZ2520SD series operates typically with a supply voltage of 1.8V, 2.5V or 3.3V. Refer to the manufacturer's datasheet for detailed specifications, including frequency tolerance, operating temperature range, and load capacitance. The frequency tolerance of the crystal oscillator is usually measured in parts per million (PPM). Load capacitance refers to the external capacitance necessary for the oscillator to function correctly at its specified frequency. Proper application of external components is crucial.

This oscillator provides accurate timing signals for various electronic applications.
