Same model may have multiple batches, images only for reference.
78615/1MC Real Image
Same model may have multiple batches, images only for reference.

78615/1MC

Part No 78615/1MC
Manufacturer Murata Power Solutions Inc.
Catalog Pulse Transformers
Description PULSE XFMR 1CT:1CT 2MH
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Transformers
Manufacturer Murata Power Solutions Inc.
Packaging Tube
Transformer Type General Purpose
Inductance 2mH
ET (Volt-Time) 20VμS
Mounting Style SMD
Parts Dimension 0.375" L x 0.354" W (9.52mm x 9.00mm)
Height - Seated (Maximum) 0.250" (6.35mm)
Temperature Range - Operating 0°C ~ 70°C
Manufacturer Pack Quantity 50
MSL Level 1 (Unlimited)
Win Source Part Number 736652-78615/1MC
Popularity Low
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian 78615/1MC CAD Model

Description

The 78615/1MC is a general purpose transformer from Murata Power Solutions Inc.. It is designed for SMD mounting and has an inductance of 2mH.

  • Mounting: SMD
  • Inductance: 2mH
  • Height: 0.250" (6.35mm)
  • Category: Transformers
  • Operating Temperature: 0°C ~ 70°C
  • Packaging: Tube
