Same model may have multiple batches, images only for reference.
53048-0910 Real Image
Same model may have multiple batches, images only for reference.

53048-0910

Part No 53048-0910
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description Conn Shrouded Header (4 Sides) HDR 9 POS 1.25mm Solder RA Thru-Hole PicoBlade™ Frame
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Body Plating Tin
Color Natural
Contact Gender Male
Contact Material Brass, Tin
Contact Plating Tin
Contact Resistance 20 mΩ
Country of Origin US
Current Rating 1 A
Depth 13.59 mm
Gender Male
Glow Wire Compliant Non-compliant
Height 3.7 mm
Housing Color Black
Housing Material Nylon
Insulation Resistance 100 MΩ
Lead Free Yes
Lead Pitch 1.25 mm
Length 20.33 mm
Max Current Rating 3 A
Maximum Operating Temperature 85 °C
Max Voltage Rating (AC) 250 V
Min Operating Temperature -40 °C
Mount Through Hole
Number of Circuits 9
Number of Contacts 9
Number of Pins 9
Number of Poles 9
Number of Positions 9
Number of Rows 1
Orientation Right Angle
Pitch 1.25 mm
Plating Tin
Radiation Hardening No
REACH SVHC Unknown
RoHS Compliant
Termination Solder
Voltage Rating 125 V
Voltage Rating (AC) 125 V
Voltage Rating (DC) 125 V
Working Voltage 125 V
Win Source Part Number 1012100-53048-0910
Categories Circular Connectors - Housings
Manufacturer Molex, LLC
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian 53048-0910 CAD Model

Description

The 1012100-53048-0910 from Molex, LLC is a male circular connector housing with 9 positions and a pitch of 1.25mm.

  • Positions: 9
  • Pitch: 1.25mm
  • Color: Natural
  • Material: Nylon
  • Contact Material: Brass with tin plating
  • Voltage Rating: 125V
  • Current Rating: 1A
  • Contact Resistance: 20mΩ
  • Insulation Resistance: 100MΩ
  • Mounting: Through-hole
  • Orientation: Right-angle
