The Molex 502790-8091 is a Flat Flex Cable (FFC) designed for connecting electronic components in a compact and flexible manner. This cable is characterized by its high density and ability to bend and flex without compromising signal integrity. Molex is a leading global manufacturer of interconnect solutions, known for their high-quality and reliable products. The 502790-8091 FFC is engineered to provide secure and stable connections in space-constrained applications.

Applications

• LCD displays
• Laptop computers
• Mobile phones
• Printers
• Digital cameras

Features

• High-density contact arrangement for space savings
• Flexible construction for easy routing
• Durable materials for long-term reliability
• Shielded options available for EMI protection
• RoHS compliant, ensuring environmental responsibility

Benefits

• Enables compact and lightweight designs
• Simplifies assembly and maintenance with its flexible nature
• Provides reliable signal transmission in demanding environments
• Reduces electromagnetic interference for improved system performance
• Meets industry standards for safety and environmental compliance

Additional Details

The 502790-8091 FFC typically consists of a flat, flexible insulation material with multiple parallel conductors. The conductors are usually made from copper or copper alloy, and the insulation material is often polyester or polyimide. The cable is designed to mate with a compatible FFC connector, providing a secure and reliable connection. Proper installation and handling are essential to prevent damage to the cable and ensure optimal performance. Detailed specifications regarding pitch, number of conductors, and voltage rating can be found in the Molex datasheet.
