46012-3142 Real Image
Same model may have multiple batches, images only for reference.

46012-3142

Part No 46012-3142
Manufacturer Molex, LLC
Catalog Circular Connectors
Description Mini-Fit Plus; 46012 Series Number PCB Conn Contact; Male; Crimp; Tin Plating 16 AWG
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Connector Type Connector, PCB, Power, Signal
Contact Gender Male
Contact Material Copper
Contact Plating Tin
Contact Resistance 10 mΩ
Country of Origin US
Current Rating 13 A
Depth 3.6 mm
Gender Male
Halogen Free Low Halogen
Height 4.5 mm
Insulation Resistance 1 GΩ
Length 16.8 mm
Max Current Rating 12 A
Mount Cable
Orientation Straight
Packaging Cut Tape
Plating Tin
REACH SVHC Unknown
RoHS Compliant
Shielding Unshielded
Termination Crimp
Voltage Rating 600 V
Voltage Rating (AC) 600 V
Wire/Cable Gauge 16 AWG
Win Source Part Number 1190354-46012-3142
Categories Circular Connectors
Manufacturer Molex, LLC
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian 46012-3142 CAD Model

Description

The Molex, LLC product is a PCB power and signal connector with a crimp termination style. It is a male gender connector with a contact material of copper and a contact plating of tin.

  • Product: PCB power and signal connector
  • Termination Style: Crimp
  • Gender: Male
  • Contact Material: Copper
  • Contact Plating: Tin
  • Voltage Rating: 600V
  • Current Rating: 13A
  • Mount: Cables
  • Wire/Cable Gauge: 16AWG
  • RoHS Compliant: Yes
  • Halogen Content: Low halogen
  • Supply and Demand Status: Limited
