0022041131

Name: 0022041131
Brand: Molex, LLC
SKU: 1332772
Availability: InStock
Rating: 4.84 (5 reviews)

Get a Quote

Part No	0022041131
Manufacturer	Molex, LLC
Catalog	Rectangular Connectors
Description	CONN HEADER VERT 13POS 2.5MM / Connector Header Through Hole 13 position 0.098" (2.50mm)
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Connectors, Interconnects>Rectangular Connectors>Headers, Male Pins
Manufacturer	Molex
Packaging	Bulk
Connector Type	Header
Contact Type	Male Pin
Pitch - Mating	0.098" (2.50mm)
Number of Positions	13
Number of Rows	1
Number of Positions Loaded	All
Style	Board to Cable/Wire
Shrouding	Shrouded - 1 Wall
Mounting	Through Hole
Termination	Solder
Fastening Type	Friction Lock
Contact Length - Mating	0.295" (7.49mm)
Contact Length - Post	0.134" (3.40mm)
Overall Contact Length	0.559" (14.20mm)
Insulation Height	0.461" (11.70mm)
Contact Shape	Square
Contact Finish - Mating	Tin
Contact Finish Thickness - Mating	200.0µin (5.08µm)
Contact Finish - Post	Tin
Contact Material	Brass
Insulation Material	Polyamide (PA), Nylon
Material Flammability Rating	UL94 V-0
Insulation Color	Natural
Base Product Number	002204
RoHS Status	ROHS3 Compliant
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8536.69.4040
Other Part Number	0022041131-E,22041131-E,WM18796-ND,WM18796,22-04-1131,0022-04-1131,23-0022041131,22-04-1131-E,22-04-1131-ND,5045-13A,22041131,0022-04-1131-E
Standard Package	1
Win Source Part Number	1332772-0022041131
Ultra Librarian 3D Model	Ultra Librarian 0022041131 CAD Model

Description

The Molex 1332772-0022041131 is a 13-position male pin header connector that is board to cable/wire style.

Positions: 13
Style: Board to Cable/Wire
Pitch-Mating: 0.098 inches
Mounting: Through-Hole
Contact Finish-Mating: Tin
Contact Finish Thickness: 200.0μin (5.08μm)
Packaging: Bulk
Shrouding: Shrouded-1 Wall
ROHS3 Compliant: Yes
Current Rating: Amps
Win Source Part Number: 1332772-0022041131
