Product Overview: PIC16F1938-I/SS

The PIC16F1938-I/SS is a versatile 8-bit microcontroller designed and manufactured by the renowned Microchip Technology. This powerful MCU comes from the PIC16F family, known for its high performance, enhanced features, and flexibility in a wide range of applications. The PIC16F1938-I/SS is particularly well-suited for embedded systems that require low power consumption and a high degree of programmability.

Encased in a 28-lead SSOP (Shrink Small Outline Package), this microcontroller offers ample I/O options for interfacing with external peripherals. The PIC16F1938-I/SS operates on a wide voltage range from 2.3V to 5.5V, allowing it to be used in various environments and systems without the need for additional power regulation hardware.

Key features of the PIC16F1938-I/SS include:

• Enhanced Mid-range Core with 49 Instruction, 16 Stack Levels
• Flash Program Memory: 14KB (8K x 14)
• SRAM: 512 bytes
• Data EEPROM: 256 bytes
• 32 MHz Max. CPU Speed with an internal oscillator for flexibility and cost reduction
• 25 I/O Pins with individual direction control
• 12-Channel 10-bit Analog-to-Digital Converter (ADC) for analog sensing capabilities
• Two Comparators with selectable voltage reference
• Enhanced Capture/Compare/PWM (ECCP) module for advanced motor control and other PWM applications
• Serial Communication with EUSART for RS-232, RS-485, and LIN compatible interfaces
• Two MSSP serial ports for SPI and I2C communication
• Integrated Watchdog Timer (WDT) to ensure reliable operation
• In-Circuit Serial Programming™ (ICSP™) and In-Circuit Debug (ICD) via two pins

The PIC16F1938-I/SS is highly customizable with Microchip's MPLAB® IDE and the MPLAB® XC8 compiler, making development quick and efficient. Its rich set of peripherals and low power consumption make it ideal for a variety of applications, including industrial automation, consumer electronics, automotive systems, and IoT devices.

With its robust feature set and Microchip's commitment to quality, the PIC16F1938-I/SS is a reliable choice for designers looking to create sophisticated and power-conscious applications.
