Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Estimated Pruduction Lead Time 8 Weeks
Features Half-Bridge Gate Driver IC Non-Inverting 10-TDFN (2.5x2.5)
Manufacturer Microchip Technology
Package Reel - TR
Operating Temperature Range -40°C ~ 125°C (TJ)
Mounting Surface Mount
Package 10-UFDFN Exposed Pad
Case / Package 10-TDFN (2.5x2.5)
Family Name MIC4605
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Other Part Number 1611-MIC4605-2YMT-CT, 1611-MIC4605-2YMT-DKR-ND, 576-4464-6, 1611-MIC4605-2YMT-CTINACTIVE, 576-4464-1, MIC4605-2YMT TR, 1611-MIC4605-2YMT-CT-ND, 1611-MIC4605-2YMT-DKR, 576-4464-2, 1611-MIC4605-2YMT-DKRINACTIVE
Quantity per package 5000
Popularity High
Supply and Demand Status Balance
Win Source Part Number 927087-MIC4605-2YMT-TR
Ultra Librarian 3D Model Ultra Librarian MIC4605-2YMT-TR CAD Model

Description

The MIC4605-2YMT-TR is a sophisticated half-bridge MOSFET driver from Microchip Technology, designed to cater to a wide array of applications requiring efficient power management and delivery. This driver is specifically engineered to drive both the high side and the low side N-channel MOSFETs in a synchronous buck or a full-bridge configuration.

Key Features

  • Adaptive Dead-Time Management: The MIC4605-2YMT-TR features an adaptive dead-time circuit that automatically adjusts the dead-time between high-side and low-side MOSFETs, which helps to maximize power efficiency and minimize cross-conduction losses.
  • Shoot-Through Protection: Integrated shoot-through protection safeguards the MOSFETs against damage by preventing both high-side and low-side MOSFETs from conducting simultaneously.
  • High-Speed Operation: With a fast 35ns propagation delay and a 20ns driver rise and fall times, this driver is suitable for high-frequency power conversion, ensuring swift and precise control over the switching MOSFETs.
  • Wide Operating Voltage Range: The device operates over a supply voltage range of 5.5V to 16V, making it versatile for various power systems.
  • Thermal Shutdown: An integrated thermal shutdown feature provides additional protection by turning off the driver if the chip temperature exceeds safe operating limits.

Applications

The MIC4605-2YMT-TR is ideal for a variety of applications, including:

  • DC/DC Converters
  • Motor Control Circuits
  • Power Supplies
  • Class D Audio Amplifiers
  • Brushless DC Motors

Package and Availability

The driver is available in a compact 10-pin 4mm x 4mm TDFN package, ensuring a minimal footprint on the PCB. The "TR" suffix indicates tape and reel packaging, which is suitable for automated assembly processes. The MIC4605-2YMT-TR is RoHS compliant and lead-free, meeting environmental standards for electronic components.

With its advanced features and robust design, the MIC4605-2YMT-TR from Microchip Technology stands out as a reliable choice for designers looking to optimize their power management systems.
