The MCP73831T-2ATI/MC from Microchip Technology is a highly integrated linear charge management controller designed for single-cell Lithium-Ion (Li-Ion) or Lithium-Polymer (Li-Po) batteries. This miniature and versatile charge management solution is housed in a tiny 5-TDFN package, making it an ideal choice for space-constrained applications.

This advanced charge management controller features a programmable charge current from 15mA to 500mA, allowing designers to tailor the charging capabilities to match specific battery requirements. The MCP73831T-2ATI/MC incorporates a host of safety features, including pre-conditioning of deeply discharged batteries, a constant current/constant voltage charge algorithm, and automatic charge termination.

With an impressive input voltage range of 3.75V to 6.0V, the MCP73831T-2ATI/MC can operate efficiently with a variety of power sources. Its precision voltage regulation of 4.2V (±0.5%) ensures that the battery is charged to its maximum capacity without risking overcharging, which can extend the life of the battery.

Furthermore, the device boasts a selectable charge termination by an external resistor, which provides additional flexibility. The MCP73831T-2ATI/MC also includes a status output that indicates charging activity, which can be used to drive an external LED or interface with a microcontroller for more advanced battery monitoring.

The MCP73831T-2ATI/MC is an ideal solution for a wide range of portable applications, such as Bluetooth headsets, wearable devices, smartwatches, and other compact electronic products that require efficient, safe, and reliable battery charging capabilities.

With its compact design, advanced features, and ease of integration, the MCP73831T-2ATI/MC offers a comprehensive and cost-effective charging solution for single-cell Li-Ion and Li-Po battery-powered applications.
