The MCP2200-I/SO is a highly integrated USB-to-UART serial converter manufactured by Microchip Technology. It offers a simple and cost-effective solution for adding USB connectivity to applications with a UART interface. The device is housed in a compact SOIC-14 package, making it suitable for space-constrained applications.

Key Features

• USB 2.0 Compliant: The MCP2200 supports full-speed USB 2.0 communication, ensuring high data transfer rates and compatibility with a wide range of USB hosts.
• Integrated USB Transceiver: The device includes a built-in transceiver, eliminating the need for external USB-specific components and reducing the overall BOM cost.
• UART Interface: It provides a simple UART interface, with baud rates ranging from 300 to 1 Mbps, which can be easily interfaced with microcontrollers or other UART-enabled devices.
• 256 Bytes of User EEPROM: This EEPROM can be utilized to store configuration data, such as vendor ID, product ID, and other USB descriptors, which can be customized to suit specific application requirements.
• Configurable GPIO: Eight general-purpose I/O pins are available and can be configured via USB commands, providing additional flexibility for control and monitoring tasks.
• Low Power Consumption: The MCP2200-I/SO is designed for low power operation, making it suitable for battery-powered and portable applications.
• Driver Support: Compatible with standard drivers available in most operating systems, which facilitates easy integration and reduces development time.

Applications

The MCP2200-I/SO is versatile and can be used in various applications such as:

• Industrial Control Systems
• Point-of-Sale Systems
• Medical Devices
• Data Acquisition Systems
• PC Peripheral Devices

In summary, the Microchip MCP2200-I/SO offers a reliable and straightforward way to add USB connectivity to virtually any UART-based application. Its integration of essential USB and UART functions, along with customizable options, makes it a popular choice for developers looking to streamline their designs and accelerate time-to-market.
