Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Estimated Pruduction Lead Time 51 Weeks
Features Current Monitor Regulator High-Side 10mA 8-MSOP
Manufacturer Microchip Technology
Package Reel - TR
Operating Temperature Range -40°C ~ 85°C
Mounting Surface Mount
Package 8-TSSOP, 8-MSOP (0.118", 3.00mm Width)
Case / Package 8-MSOP
Family Name HV7802
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Other Part Number HV7802MG-G-ND, HV7802MG-GCT, HV7802MG-GDKR, HV7802MG-GTR
Quantity per package 2500
Popularity Medium
Supply and Demand Status Limited
Win Source Part Number 844160-HV7802MG-G
Ultra Librarian 3D Model Ultra Librarian HV7802MG-G CAD Model

Description

Microchip Technology's HV7802MG-G High-Voltage Driver

The HV7802MG-G, a robust and versatile high-voltage driver from Microchip Technology, is designed to deliver exceptional performance in a wide array of applications requiring high-voltage driving capabilities. This driver is particularly well-suited for driving piezoelectric, LED, and LCD loads, making it an ideal choice for designers looking to create efficient and reliable solutions for industrial, automotive, and consumer electronics markets.

Key Features:

  • High Output Drive Capability: The HV7802MG-G is capable of driving high-voltage loads, offering a wide operating voltage range that ensures flexibility in various design scenarios.
  • Low Quiescent Current: Efficiency is at the core of this driver, with a low quiescent current that minimizes power consumption when the driver is in a static state, thereby enhancing battery life in portable applications.
  • Thermal Shutdown Protection: To ensure the reliability and longevity of the device, the HV7802MG-G comes equipped with thermal shutdown protection, which prevents damage from overheating.
  • High-Speed Operation: The device supports high-frequency operation, which is crucial for applications requiring quick response times and high-speed switching.

Applications:

  • LED Lighting Systems
  • LCD Backlight Inverters
  • Piezoelectric Transducer Drivers
  • Industrial and Automotive Electronics

The HV7802MG-G is housed in a compact package, making it suitable for space-constrained applications while offering the robustness needed for demanding environments. With its high-level integration, this driver simplifies circuit design and reduces the need for external components, thus reducing overall system cost and complexity.

Overall, Microchip Technology's HV7802MG-G high-voltage driver is an excellent choice for engineers and designers seeking a reliable, high-performance solution for their high-voltage driving needs. Its combination of power efficiency, thermal protection, and high-speed operation makes it a versatile component in creating cutting-edge electronic products.
