Products specifications Report Issue?

Win Source Part Number WS1203094-DSPIC33EP64MC506T-E/PT
Win Source Part Number Cross
Manufacturer Microchip Technology
Category Integrated Circuits (ICs) Embedded Microcontrollers
Series Automotive, AEC-Q100, dsPIC™ 33EP
Package Tape & Reel (TR)
Product Status Obsolete
Core Processor dsPIC
Core Size 16-Bit
Speed 60 MIPs
Connectivity CANbus, I²C, IrDA, LINbus, QEI, SPI, UART/USART
Peripherals Brown-out Detect/Reset, DMA, Motor Control PWM, POR, PWM, WDT
Ultra Librarian 3D Model Ultra Librarian DSPIC33EP64MC506T-E/PT CAD Model

Description

Microchip Technology's DSPIC33EP64MC506T-E/PT Product Overview

The DSPIC33EP64MC506T-E/PT is a high-performance digital signal controller (DSC) from Microchip Technology, renowned for its advanced features and capabilities that make it an ideal choice for a wide range of applications. This DSC integrates the processing power of a digital signal processor (DSP) with the functionality of a microcontroller (MCU), providing a versatile solution for complex embedded systems.

Key Features

  • Core: The device features a 70 MIPS dsPIC33E core, with DSP-enhanced instructions for optimal processing performance.
  • Program Memory: It comes with 64 KB of flash memory, allowing for robust program storage.
  • RAM: The DSC is equipped with 8 KB of RAM, facilitating efficient data manipulation and storage.
  • I/O Pins: With 53 programmable I/O pins, it provides ample interfacing options for peripherals and external devices.
  • Timers and Communication Interfaces: The device includes multiple timers, input capture, output compare, and communication interfaces such as I²C, SPI, and UART for versatile connectivity.
  • Enhanced Analog Features: It boasts a 12-bit, 16-channel ADC, three comparators, and a Charge Time Measurement Unit (CTMU) for advanced analog integration.
  • Operating Voltage: The operating voltage range of 3.0V to 3.6V ensures compatibility with a variety of power supplies and systems.
  • Temperature Range: With an extended industrial temperature range, it can operate reliably in environments from -40°C to +125°C.

Applications

The DSPIC33EP64MC506T-E/PT is designed to cater to applications that require high computational performance and real-time processing. It is commonly used in motor control, power supplies, industrial automation, automotive systems, and consumer electronics. Its robust set of features also makes it suitable for Internet of Things (IoT) devices, medical instrumentation, and communication systems.

Quality and Reliability

As with all Microchip products, this DSC is manufactured to the highest quality standards, ensuring both reliability and longevity in the field. Its extended temperature range and robust feature set make it a trustworthy component for designing systems that must perform in demanding conditions.

Whether you're developing a sophisticated control system or a high-performance embedded application, the DSPIC33EP64MC506T-E/PT from Microchip Technology offers a powerful and flexible solution to meet your design requirements.
