Microchip Technology's AT28BV16-25PC EEPROM

The AT28BV16-25PC from Microchip Technology is a high-performance Electrically Erasable Programmable Read-Only Memory (EEPROM) device that offers a robust storage solution for a wide range of applications. This device combines a fast access time of 250 nanoseconds with a non-volatile storage capability, ensuring data retention without the need for a continuous power supply.

With a 16-kilobit storage capacity, the AT28BV16-25PC is designed to meet the needs of applications requiring a moderate amount of data storage. The EEPROM is organized as 2,048 x 8 bits, which allows for efficient data management and easy integration with 8-bit microcontrollers. Its parallel interface enables quick data transfer, making it suitable for high-speed microprocessor systems.

The AT28BV16-25PC operates within a voltage range of 2.7V to 5.5V, providing flexibility for use in systems with varying power supplies. This makes it an ideal choice for battery-operated and portable devices where power conservation is crucial. Additionally, the device features low power consumption with a typical standby current of only 10 μA, further extending battery life in portable applications.

One of the key advantages of the AT28BV16-25PC is its endurance. It is rated for a minimum of 100,000 write cycles, ensuring a long operational life. The EEPROM also supports a data retention period of at least 10 years, guaranteeing the preservation of critical data over time.

The packaging of the AT28BV16-25PC is a 28-pin DIP (Dual In-line Package), which is widely used and recognized in the industry. This makes it easy to handle and solder onto a printed circuit board, as well as being suitable for prototyping and mass production environments.

Overall, the AT28BV16-25PC from Microchip Technology is a reliable and cost-effective data storage solution that combines fast access times, low power consumption, and high endurance, making it an excellent choice for a variety of electronic applications.
