Products specifications

Category Discrete Semiconductor Products>Diodes - Rectifiers - Arrays
Manufacturer Microchip Technology
Packaging Tube
Diode Configuration 2 Independent
Diode Type Standard
Voltage - DC Reverse (Vr) (Max) 600 V
Current - Average Rectified (Io) (per Diode) 30A
Voltage - Forward (Vf) (Max) @ If 1.8 V @ 30 A
Speed Fast Recovery =< 500ns, > 200mA (Io)
Reverse Recovery Time (trr) 85 ns
Current - Reverse Leakage @ Vr 250 µA @ 600 V
Mounting Chassis Mount
Case / Package SOT-227-4, miniBLOC
Supplier Device Package ISOTOP®
Base Product Number APT2X30
RoHS Status RoHS Compliant
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0080
Other Part Number APT2X30D60JMI,APT2X30D60JMI-ND
Standard Package 1
Win Source Part Number 1325759-APT2X30D60J
Ultra Librarian 3D Model Ultra Librarian APT2X30D60J CAD Model

Description

Product Overview: APT2X30D60J from Microchip Technology

The APT2X30D60J is a high-performance, power semiconductor device designed and manufactured by Microchip Technology, a leading provider of microcontroller, mixed-signal, analog, and Flash-IP solutions. This particular product is an IGBT (Insulated Gate Bipolar Transistor) module, which has been engineered to cater to a wide range of power applications, delivering both high efficiency and reliability.

Featuring a robust and durable design, the APT2X30D60J offers an optimal solution for applications requiring fast switching and high power handling capabilities. The device is characterized by its low on-state voltage drop and minimal switching losses, which contribute to its high efficiency and thermal performance, making it an excellent choice for energy-sensitive designs.

Key Features:

  • High Current Rating: The APT2X30D60J is capable of handling continuous currents, making it suitable for high-power applications.
  • High Voltage Capability: With a voltage rating, this IGBT module can be used in systems that operate at higher voltages, providing flexibility in design.
  • Low On-State Voltage: The low on-state voltage drop helps in reducing conduction losses and improves overall system efficiency.
  • Fast Switching Speed: The fast switching capability of the APT2X30D60J minimizes switching losses and enables operation at higher frequencies.
  • Robust Design: The device is built to withstand harsh conditions, ensuring reliability and a long operational life.

Applications:

The versatility of the APT2X30D60J makes it suitable for a diverse range of applications, including but not limited to:

  • Motor Drives
  • Power Inverters
  • Uninterruptible Power Supplies (UPS)
  • Induction Heating
  • Renewable Energy Systems

Microchip Technology's APT2X30D60J represents a blend of advanced semiconductor technology and design excellence, delivering a product that meets the rigorous demands of modern power electronic systems. With its high current and voltage capabilities, coupled with efficient switching performance, the APT2X30D60J is a top-tier component for designers and engineers looking to enhance the performance and reliability of their power management solutions.
