Products specifications

Manufacturer MIC GROUP RECTIFIERS
Win Source Part Number 1258566-SR2040C
Manufacturer Homepage www.cnmic.com
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian SR2040C CAD Model

Description

The SR2040C is a Schottky Barrier Rectifier manufactured by MIC GROUP RECTIFIERS. Similar to other Schottky rectifiers, it is designed for applications needing fast switching speed and low forward voltage drop. The 'C' suffix suggests it could be a common cathode configuration (though datasheet confirmation is ideal).

Applications:

  • Switching Mode Power Supplies (SMPS)
  • High-frequency rectifiers
  • Freewheeling diodes in inverters
  • DC-DC converters
  • Reverse polarity protection

Features:

  • Low forward voltage drop: Minimizes power loss and improves efficiency.
  • Fast switching speed: Reduces switching losses at high frequencies.
  • High surge current capability: Handles transient overloads effectively.
  • High junction temperature capability: Suitable for demanding thermal environments.
  • Low reverse leakage current: Improves efficiency by reducing reverse conduction losses.

Benefits:

  • Improved efficiency in power supplies: Reduces heat generation and energy waste.
  • Suitability for high-frequency circuits: Enables smaller and lighter designs.
  • Robustness against transient conditions: Increases system reliability.
  • Reliable operation in high-temperature environments: Ensures stable performance in challenging conditions.
  • Reduced power loss: Increases overall circuit efficiency.

Additional Details:

The SR2040C likely has a forward current rating of around 20A and a reverse voltage rating of 40V. As a Schottky barrier rectifier, its forward voltage drop will be significantly lower than that of a standard silicon diode. This lower voltage drop translates directly into less power dissipated as heat, leading to higher efficiency. The fast switching speed is a key advantage for high-frequency applications, minimizing switching losses and allowing for higher operating frequencies. The high surge current capability allows the rectifier to withstand transient overcurrent conditions, such as those that can occur during startup. It is typically packaged in a TO-220 or similar configuration to facilitate heat dissipation. The datasheet will provide precise values for forward voltage drop, reverse leakage current, and thermal resistance, which are essential for optimal circuit design.
