SOD4007 Real Image1 SOD4007 Real Image2
Same model may have multiple batches, images only for reference.
SOD4007 Real Image1 SOD4007 Real Image2
SOD4007 Real Image1 SOD4007 Real Image2
Same model may have multiple batches, images only for reference.

SOD4007

Part No SOD4007
Manufacturer MDD
Catalog Diodes, Rectifiers - Single
Description DIODE GEN PURP 1KV 1A SOD123FL
Datasheet
SOD4007 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Rectifiers - Single Diodes
Mfr MDD
Series SOD-123FL
Package Tape & Reel
Product Status Active
Technology Standard
Voltage - DC Reverse (Vr) (Max) 1000 V
Current - Average Rectified (Io) 1A
Voltage - Forward (Vf) (Max) @ If 1.1 V @ 1 A
Capacitance @ Vr, F 4pF @ 4V, 1MHz
Mounting Type Surface Mount
Package / Case SOD-123FL
Supplier Device Package SOD-123FL
Operating Temperature - Junction -55°C ~ 125°C
Standard Package 12,000 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 336391-SOD4007
Ultra Librarian 3D Model Ultra Librarian SOD4007 CAD Model

Description

The 336391-SOD4007 is a standard rectifier diode designed for general purpose applications.

  • Series: SOD-123FL
  • Packaging: Tape and reel
  • Maximum DC Reverse Voltage: 1000V
  • Average Rectified Current: 1A
  • Suitable for: Various rectification and power supply applications.
  • Forward Voltage: 1.1V @ 1A
  • Capacitance: 4pF @ 4V and 1MHz
  • Operating Temperature: -55°C to 125°C
  • Mounting Type: Surface mountable
  • Description: Provides reliable performance in a compact package.
