Maxim Integrated MAX9502GELT+T Product Overview

The MAX9502GELT+T from Maxim Integrated is a high-performance, low-power, DirectDrive® video filter amplifier that is specifically designed to enhance video signal quality in portable applications. This compact and efficient component is a perfect solution for small, battery-powered devices such as mobile phones, portable media players, and handheld gaming consoles, where space is at a premium and power consumption needs to be minimized.

Key Features

• DirectDrive Technology: The MAX9502GELT+T utilizes Maxim's proprietary DirectDrive technology, which eliminates the need for an output coupling capacitor. This not only saves space but also reduces component count and cost, while providing a cleaner signal path.
• High-Quality Video Performance: With a 6MHz bandwidth and a slew rate of 45V/µs, the MAX9502GELT+T delivers high-quality video performance, making it ideal for driving both composite and S-Video signals.
• Low Power Consumption: The device operates from a single 2.7V to 3.6V supply, consuming a mere 1.6mA of quiescent current, which is crucial for extending battery life in portable devices.
• Integrated Filter: It features an integrated low-pass filter that reduces noise and prevents aliasing, ensuring a clear and stable video output.
• Small Package: The MAX9502GELT+T comes in a tiny 6-pin Thin QFN package, making it an excellent choice for designs where board space is at a high premium.

Applications

The MAX9502GELT+T is versatile and can be used across a wide range of applications. Its primary use is in portable video devices, but it is also suitable for:

• Portable DVD Players
• Video Glasses
• Personal Video Recorders
• Security Cameras
• Video-Enabled Wearable Devices

Maxim Integrated's commitment to quality and innovation is evident in the MAX9502GELT+T, providing designers with a robust, high-performance video filter amplifier that meets the stringent requirements of today's portable video applications. With this component, manufacturers can deliver products with superior video quality while maintaining the compact size and extended battery life that consumers demand.
