MAX8544EEP+

Part No MAX8544EEP+
Manufacturer Maxim Integrated
Catalog PMIC - Voltage Regulators - DC DC Switching Controllers
Description IC REG CTRLR BUCK 20QSOP
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Maxim Integrated
Packaging Tube
Output Type Transistor Driver
Function Step-Down
Topology Buck
Output Phases 1
Supply Voltage 3V ~ 13.2V
Switching Frequency 800kHz ~ 1.2MHz
Synchronous Rectifier Yes
Clock Sync Yes
Control Features Current Limit, Enable, Power Good, Soft Start
Temperature Range - Operating -40°C ~ 85°C
Manufacturer Package 20-SSOP
Supplier Device Package 20-QSOP
Family Part Number MAX8544
Manufacturer Pack Quantity 50
MSL Level 1 (Unlimited)
Win Source Part Number 706774-MAX8544EEP+
Series MAX series
Popularity Low
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian MAX8544EEP+ CAD Model

Description

Maxim Integrated MAX8544EEP+ Overview

The MAX8544EEP+ from Maxim Integrated is a high-performance, low-dropout linear regulator designed to deliver a continuous 1.5A output current. It is a versatile power management solution suited for a wide range of applications, including portable devices, networking equipment, and industrial systems. The device operates from a 2.5V to 5.5V input voltage range, making it compatible with most standard power supplies and battery-operated systems.

Key Features

  • Output Current: The MAX8544EEP+ is capable of delivering up to 1.5A of continuous output current, which is ideal for powering core voltages of microprocessors and other high-power ICs.
  • Wide Input Voltage Range: With an input voltage range of 2.5V to 5.5V, the device can be powered by various sources, including single-cell Li-ion batteries or 3.3V and 5V rails.
  • Adjustable Output Voltage: The output voltage can be adjusted from 1.25V to VIN, allowing for a high degree of flexibility in matching the voltage requirements of the load.
  • High Accuracy: The MAX8544EEP+ offers excellent load and line regulation, ensuring a stable output voltage under varying conditions.
  • Low Dropout Voltage: The low dropout voltage minimizes power loss and improves efficiency, which is critical for battery-powered applications.
  • Thermal Protection: Built-in thermal shutdown protects the device and the load from damage due to excessive heat.
  • Short-Circuit Protection: The regulator includes short-circuit protection to safeguard the device and the system from faults and abnormal operating conditions.
  • Small Footprint: Housed in a 20-pin QSOP package, the MAX8544EEP+ is designed for space-constrained applications.

Applications

The MAX8544EEP+ is a versatile component suitable for a variety of applications where stable and efficient power regulation is required. Its high output current and adjustable voltage make it an excellent choice for:

  • Portable Devices: Smartphones, Tablets, and Portable Media Players
  • Networking: Routers, Switches, and Wireless Communication Devices
  • Industrial: PLCs, Sensors, and Instrumentation
  • Computing: Motherboards, Graphics Cards, and Memory Modules

With its robust feature set and compact design, the MAX8544EEP+ from Maxim Integrated stands out as a reliable power management solution for designers looking to optimize performance and efficiency in their electronic products.
