Maxim Integrated MAX7456EUI+ Monochrome On-Screen Display

The MAX7456EUI+ from Maxim Integrated is a complete on-screen display (OSD) system in a single chip, integrating the display memory, character generator, and digital-to-analog converter (DAC) necessary to create on-screen displays. This powerful IC is designed to overlay text and graphics onto a video signal with ease, making it an ideal choice for a wide range of applications in the security, automotive, and consumer electronics fields.

The MAX7456EUI+ supports NTSC and PAL video standards and can be easily interfaced with microcontrollers via an SPI-compatible serial interface. Its built-in character generator comes with 256 user-definable characters or icons, allowing for a customizable user experience. Additionally, it includes 12 x 18 pixel character cells for detailed and clear text and graphics display.

One of the key features of the MAX7456EUI+ is its non-volatile memory, which ensures that custom character data is preserved even when the power is off. This feature is especially useful for applications that require consistent branding or information display without the need for frequent reprogramming.

For ease of integration, the MAX7456EUI+ is available in a 28-pin TSSOP package, making it compact and suitable for space-constrained designs. Its single 5V supply and low power consumption enhance its suitability for portable and battery-powered devices.

Furthermore, the MAX7456EUI+ is designed with robustness in mind, featuring a built-in sync separator and video driver, which simplifies the task of overlaying graphics and text onto existing video feeds. The device can generate its own sync and video timing signals, allowing for the creation of standalone video displays or OSDs without the need for an external video source.

In summary, the Maxim Integrated MAX7456EUI+ offers a versatile and easy-to-use solution for adding high-quality on-screen displays to video signals, making it a top choice for designers looking to enhance their video-based projects with dynamic and informative graphics overlays.
