MAX490MJA - Low-Power, Slew-Rate-Limited RS-485/RS-422 Transceivers

The MAX490MJA is a high-performance transceiver from Maxim Integrated, designed for RS-485 and RS-422 communication networks. This device is particularly suited for long-distance and high-speed data communication applications where low power consumption and minimal electromagnetic interference (EMI) are crucial.

Key Features

• Slew-Rate Limited: The MAX490MJA features a controlled slew rate which limits the rate of change in the signal, reducing EMI and allowing error-free data transmission over longer cable lengths.
• Low Power: With its low-power operation, the device is ideal for energy-sensitive applications, making it a popular choice for portable and remote systems.
• Half-Duplex Communication: The transceiver supports half-duplex communication, allowing bidirectional communication on a single pair of wires, which helps in reducing the overall system cost and complexity.
• Extended Temperature Range: The MAX490MJA operates over a wide temperature range, making it suitable for industrial environments and outdoor applications.
• High Data Rates: Despite its low-power design, the device supports data rates up to 2.5Mbps, which is more than adequate for many control and automation tasks.
• Fail-Safe Receiver: The receiver inputs have a fail-safe feature that guarantees a known output state if the inputs are open or shorted.

Applications

The MAX490MJA is versatile and can be used in a variety of applications, including:

• Industrial control systems
• Building automation
• Networked security cameras
• Remote sensors
• Point-of-sale systems

Package and Quality

The device comes in a robust CERDIP package, ensuring high reliability and performance even under harsh conditions. Maxim Integrated's commitment to quality means that the MAX490MJA meets stringent industry standards for communication transceivers.

Overall, the MAX490MJA from Maxim Integrated is a reliable and efficient solution for RS-485/RS-422 communication, balancing performance with power efficiency to meet the needs of modern industrial and commercial applications.
