Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Maxim Integrated
Packaging Reel - TR
Status Active
Type Transceiver
Protocol RS422, RS485
Number of Drivers/Receivers 1/1
Duplex Half
Receiver Hysteresis 70mV
Data Rate 2.5Mbps
Supply Voltage - Operating 4.75 V to 5.25 V
Temperature Range - Operating 0°C to 70°C
Mounting SMD (SMT)
Case / Package 8-SOIC
Win Source Part Number 021791-MAX485ECSA+T
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Family Name MAX485E
Introduction Date July 01, 1996
ECCN EAR99
Country of Origin Taiwan
Halogen Free Compliant
Estimated EOL Date 2024
Ultra Librarian 3D Model Ultra Librarian MAX485ECSA+T CAD Model

Description

MAX485ECSA+T RS-485/RS-422 Transceiver

The MAX485ECSA+T from Maxim Integrated is a low-power, slew-rate-limited device designed for RS-485 and RS-422 communications. This transceiver is particularly suitable for long bus lengths in noisy industrial environments. The MAX485ECSA+T is a half-duplex transceiver, meaning it can both transmit and receive data but not simultaneously, which is ideal for networked, multi-point systems.

Encased in an 8-pin SOIC package, the MAX485ECSA+T operates from a single 5V supply, making it compatible with many microcontrollers and digital systems. Its low quiescent current of 300µA (typical) and 1µA in low-power shutdown mode ensures energy-efficient operation, which is critical for battery-powered and remote systems.

The device supports data rates up to 2.5Mbps, making it a good fit for applications that require moderate speed data transfer. Additionally, the integrated thermal shutdown and current-limiting features provide protection against faulty conditions, improving the reliability and longevity of the communication system.

The MAX485ECSA+T is designed with fail-safe features that ensure a logic-high receiver output when the receiver inputs are open or shorted, or when they are connected to a terminated transmission line with all drivers disabled. This feature greatly enhances the robustness of the system it is integrated into.

Applications for the MAX485ECSA+T are diverse and include industrial control systems, building automation, networked security systems, and any other systems that require a reliable RS-485 or RS-422 communication interface. The transceiver is also available in a tape and reel form, making it suitable for automated manufacturing processes.

Maxim Integrated's commitment to quality and reliability is evident in the MAX485ECSA+T transceiver, which is designed to meet the stringent demands of industrial communication networks. With its combination of low-power operation, protection features, and fail-safe receiver, the MAX485ECSA+T is an excellent choice for designers looking to implement robust and efficient data communication in their systems.
