The MAX4382EEE+T from Maxim Integrated is a cutting-edge operational amplifier designed for applications requiring high-speed signal processing with minimal noise interference. This product is part of Maxim's family of high-speed, low-noise amplifiers that offer a superb balance between speed and power consumption, making it an ideal choice for a wide range of electronic applications.

Key Features

• High-Speed Performance: With a bandwidth of 210MHz at a gain of +2V/V, the MAX4382EEE+T is capable of high-speed signal amplification, suitable for video, communication, and instrumentation applications.
• Low Noise: The device has a low input-referred voltage noise density of 2.9nV/√Hz, ensuring clear signal amplification with minimal distortion.
• Low Power Consumption: Despite its high-speed capabilities, this amplifier maintains low power consumption, with a quiescent current of just 5.1mA per amplifier.
• Rail-to-Rail Outputs: The amplifier supports rail-to-rail output swings, which allows for maximum dynamic range in signal processing.
• Single-Supply Operation: It operates from a single +3V to +5.5V supply, simplifying power supply design.

Applications

• Video and broadcast equipment
• High-speed data acquisition systems
• Communications infrastructure
• Medical imaging devices
• Test and measurement instruments

Product Specifications

The MAX4382EEE+T is offered in a compact 16-pin QSOP package, making it suitable for space-constrained applications. Its extended temperature range of -40°C to +85°C ensures reliable performance across various environmental conditions. The device also features a disable function that reduces power consumption when the amplifier is not in use.

Ordering Information

The product is available in tape and reel form, denoted by the '+T' suffix, facilitating easy integration into automated manufacturing processes. This makes the MAX4382EEE+T a practical choice for mass production requirements.
