Maxim Integrated MAX14656EWE+T USB 2.0 Hi-Speed Multiplexer/Switch

The MAX14656EWE+T from Maxim Integrated is a versatile and high-performance USB 2.0 Hi-Speed (480Mbps) multiplexer/switch designed to enable USB 2.0 signal switching with minimal signal degradation. This device is an ideal solution for applications requiring USB signal routing, such as docking stations, peripherals, and multi-function printers.

With its integrated ESD protection, the MAX14656EWE+T provides robust protection for sensitive USB lines against electrostatic discharges, ensuring the reliability and longevity of your USB applications. The device features low on-capacitance (CON) and on-resistance (RON), which results in minimal signal distortion and attenuation, thus preserving signal integrity for high-speed data transmission.

The MAX14656EWE+T offers a wide operating temperature range from -40°C to +85°C, making it suitable for various environments and applications. Its compact 16-pin WLP (Wafer-Level Package) with a 1.8mm x 1.6mm footprint allows for space-saving designs, which is particularly beneficial for portable and space-constrained devices.

This USB 2.0 switch supports both full-speed (12Mbps) and low-speed (1.5Mbps) operation, providing flexibility for various USB configurations. It is also designed with a single supply voltage of 3.0V to 5.5V, which aligns with common USB bus power specifications, simplifying power supply design.

Key features of the MAX14656EWE+T include:

• USB 2.0 Hi-Speed (480Mbps) compatible
• Integrated ESD protection for enhanced reliability
• Low on-capacitance and on-resistance to maintain signal quality
• Wide operating temperature range for diverse applications
• Compact 16-pin WLP for space-saving designs
• Support for full-speed and low-speed USB operation
• Single supply voltage for ease of design

The MAX14656EWE+T is supplied in a tape and reel format (denoted by the +T suffix), which is suitable for automated pick-and-place manufacturing processes, ensuring efficient assembly for high-volume production. With its combination of performance, integration, and compactness, the MAX14656EWE+T is an excellent choice for designers looking to streamline their USB interface designs while maintaining high-speed data integrity and protection.
