Products specifications Report Issue?

Mounting SMD (SMT)
Case / Package BGA
Data Rate 64 kbps
Lead Free Yes
Maximum Operating Temperature 70 °C
Max Supply Current 328 mA
Max Supply Voltage 3.465 V
Min Operating Temperature 0 °C
Min Supply Voltage 3.135 V
Mount Surface Mount
Number of Pins 256
Number of Transceivers 4
Operating Supply Voltage 3.3 V
Radiation Hardening No
RoHS Compliant
Win Source Part Number 1020509-DS21455+
Categories Interface - Specialized
Manufacturer Maxim Integrated
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian DS21455+ CAD Model

Description

Maxim Integrated's DS21455+ Multichannel T1/E1/J1 Short-Haul Transceiver

The Maxim Integrated DS21455+ is a versatile and high-performance multichannel T1/E1/J1 short-haul transceiver designed to meet the needs of telecommunications and data communications applications. This advanced IC is part of Maxim's extensive line of telecom products, offering a robust set of features that enable it to handle multiple telecom interfaces with ease and efficiency.

The DS21455+ supports both T1 and E1 data rates, as well as the J1 Japanese standard, making it a flexible solution for systems that require interoperability across different geographic regions and standards. With its integrated line interface unit (LIU) and framer for each channel, the DS21455+ can manage up to four T1 (1.544Mbps) or E1 (2.048Mbps) lines, providing significant savings in both board space and cost.

One of the key features of the DS21455+ is its capability to operate in either independent or multiframe alignment modes, accommodating a wide range of communication protocols. Additionally, the device includes a built-in jitter attenuator on both the receive and transmit sides, ensuring signal integrity and reducing the effects of transmission jitter in the communication line.

The transceiver also boasts a crystal-less jitter attenuator, which simplifies the design by eliminating the need for an external crystal or resonator. This feature not only reduces the bill of materials but also enhances reliability by reducing the number of external components required.

For diagnostics and network management, the DS21455+ comes equipped with a comprehensive set of built-in test features, including loopbacks and pattern generators/checkers for each channel. These features facilitate easy system testing and troubleshooting, which is crucial for maintaining high availability and performance in mission-critical systems.

Designed with power efficiency in mind, the DS21455+ operates on a single 3.3V power supply, minimizing power consumption and making it suitable for a variety of platforms, including multiplexers, routers, and switches. Its compact 100-pin TQFP package allows for a reduced footprint on the PCB, making it an ideal choice for space-constrained applications.

In conclusion, the Maxim Integrated DS21455+ is a highly integrated and feature-rich multichannel T1/E1/J1 transceiver that delivers performance, flexibility, and reliability for telecommunications equipment manufacturers and system integrators.
