The DG406CJ is a high-performance, single-ended, 16-channel multiplexer designed by Maxim Integrated. This precision analog multiplexer is a versatile component that allows users to route one of 16 single-ended inputs to a common output as determined by the 4-bit binary address lines. Its exceptional design makes it a suitable choice for applications requiring a reliable and efficient means to manage multiple signal inputs through a single channel.

Key Features

• Wide Voltage Range: Operates with a dual ±5V to ±18V or a single 10V to 36V power supply, providing flexibility in various circuit configurations.
• Low On-Resistance: Features a low on-resistance (100Ω max), which minimizes signal attenuation and ensures high signal integrity.
• Low Leakage: Exhibits low off-channel leakage current (100pA at +25°C) and on-channel leakage current (5nA at +25°C), which enhances the precision of the system.
• Fast Switching: Offers fast transition times with t<sub>TRANSITION of 250ns max, which allows for quick signal switching and is beneficial in time-sensitive applications.
• ESD Protection: Provides Electrostatic Discharge (ESD) protection for increased robustness in harsh environments.

Applications

The DG406CJ is well-suited for a variety of applications that require multiplexing of high-speed signals, including:

• Data Acquisition Systems
• Test Equipment
• Audio/Video Signal Routing
• Communication Systems
• Industrial Control Systems

Package and Quality

The DG406CJ comes in a 24-pin DIP (Dual In-line Package), which is easy to handle and integrate into a wide range of electronic systems. Maxim Integrated ensures high-quality standards, and the DG406CJ is no exception, providing reliable performance even in demanding conditions.

Conclusion

Maxim Integrated's DG406CJ multiplexer is a testament to the company's commitment to delivering high-performance integrated circuits. Its combination of low on-resistance, low leakage currents, and fast switching capabilities make it an excellent choice for designers looking to optimize their signal routing with precision and efficiency.
