The MDP5N50ZTH is a Power MOSFET from MagnaChip Semiconductor. It is designed for high-voltage, high-speed switching applications. This MOSFET offers low on-resistance and gate charge, making it suitable for efficient power conversion and motor control.

Applications

• Switch-Mode Power Supplies (SMPS): Used as a switching element in various SMPS topologies.
• Power Factor Correction (PFC): Enables efficient power factor correction in power supplies.
• DC-DC Converters: Implements efficient DC-DC conversion in a variety of applications.
• Motor Control: Used in motor control circuits for switching and power amplification.
• Lighting Ballasts: Enables efficient switching in electronic lighting ballasts.

Features

• High Voltage: Features a high drain-source breakdown voltage of 500V, suitable for high-voltage applications.
• Low On-Resistance: Offers low on-resistance (RDS(on)), minimizing power loss and improving efficiency.
• Low Gate Charge: Low gate charge reduces switching losses and improves efficiency at high frequencies.
• Fast Switching Speed: Provides fast switching speed for efficient operation in switching applications.
• Avalanche Ruggedness: Designed with avalanche ruggedness for reliable operation in demanding applications.
• RoHS Compliant: Compliant with RoHS directives, ensuring environmental friendliness.

Benefits

• High Efficiency: Low on-resistance and low gate charge minimize power loss and improve efficiency.
• Improved Performance: Fast switching speed enhances the performance of switching applications.
• Enhanced Reliability: Avalanche ruggedness ensures reliable operation in demanding applications.
• Simplified Design: Reduces the complexity of circuit design by providing a highly efficient and reliable power MOSFET.
• Versatile Application: Suitable for a wide range of applications due to its high voltage, low on-resistance, low gate charge, and fast switching speed.

Additional Details

The MDP5N50ZTH is typically available in a TO-220 package. It is designed to operate within a specific temperature range and is characterized by its high-voltage capability and low conduction losses. Detailed specifications regarding RDS(on), gate charge, drain current, and other parameters can be found in the MagnaChip datasheet.
