Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category Integrated Circuits (ICs) - Memory - Memory
Mfr Macronix
Series MXSMIO™
Package Tape & Reel
Product Status Active
Programmable Not Verified
Memory Type Non-Volatile
Memory Format FLASH
Technology FLASH - NOR
Memory Size 16Mbit
Memory Organization 2M x 8
Memory Interface SPI - Quad I/O
Clock Frequency 80 MHz
Write Cycle Time - Word, Page 100µs, 4ms
Voltage - Supply 1.65V ~ 3.6V
Temperature Range - Operating -40°C ~ 85°C (TA)
Mounting Type Surface Mount
Package / Case 8-UFDFN Exposed Pad
Supplier Device Package 8-USON (2x3)
Base Product Number MX25R1635
Standard Package 12,000 pcs
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.32.0071
Win Source Part Number 848770-MX25R1635FZUIH0
Ultra Librarian 3D Model Ultra Librarian MX25R1635FZUIH0 CAD Model

Description

The MX25R1635FZUIH0 is a high-performance memory integrated circuit designed for non-volatile storage applications manufactured by Macronix.

  • Memory Size: 16Mbit
  • Voltage Range: 1.65V to 3.6V
  • Clock Frequency: 80MHz
  • Temperature Range: -40°C to 85°C
  • Package: 8-UFDFN Exposed Pad
  • Mounting Type: Surface Mount
