The Macronix 29F002T-90 is a 2-Megabit Flash Memory device organized as 256K x 8. This memory is fabricated with Macronix’s proprietary, high-performance CMOS technology. It features a fast access time of 90ns, making it suitable for applications requiring rapid data retrieval and storage.

Applications

• Embedded systems: The 29F002T-90 is used in embedded systems for storing firmware, boot code, and configuration data.
• Industrial control systems: This flash memory is employed in industrial control systems for program storage and data logging.
• Networking devices: It finds application in networking equipment for storing network configurations and boot images.
• Consumer electronics: Used in various consumer electronics devices such as set-top boxes, gaming consoles (older models), and other devices requiring non-volatile memory.
• Instrumentation: Employed in instrumentation equipment for storing calibration data and program code.

Features

• Fast Access Time: 90 ns access time for quick data retrieval.
• Single 5V Power Supply: Operates on a single 5V power supply simplifying system design.
• Sector Architecture: Provides sector erase capability, allowing for selective erasure and reprogramming of memory blocks.
• CMOS Technology: Fabricated with high-performance CMOS technology for low power consumption and high reliability.
• JEDEC Standard Pinout: Adheres to JEDEC standard pinout for easy integration into existing designs.
• Automatic Write Protection: Incorporates automatic write protection to prevent accidental data corruption.
• Endurance: High endurance, typically specified at 100,000 erase/write cycles per sector.
• Data Retention: Long data retention, typically specified at 10 years.

Benefits

• Fast Performance: The fast access time ensures quick program execution and data retrieval, enhancing system performance.
• Easy Integration: The JEDEC standard pinout simplifies integration into existing designs, reducing development time and cost.
• Reliable Data Storage: The high endurance and data retention characteristics ensure reliable data storage over an extended period.
• Cost-Effective: Provides a cost-effective solution for non-volatile memory requirements in various applications.
• Low Power Consumption: The CMOS technology enables low power consumption, making it suitable for battery-powered devices.
• Flexible Memory Management: Sector erase capability allows for flexible memory management and efficient utilization of memory resources.

Technical Specifications:

• Organization: 256K x 8
• Access Time: 90 ns
• Supply Voltage: 5V
• Operating Temperature: -40°C to +85°C
• Package: DIP32, PLCC32, TSOP32

The 29F002T-90 is available in various packages, including DIP32, PLCC32, and TSOP32, providing flexibility in PCB design and manufacturing. Its wide operating temperature range makes it suitable for use in harsh environments. The device supports both sector erase and chip erase operations, allowing for flexible memory management and efficient utilization of memory resources. With its fast access time, high endurance, and reliable data storage capabilities, the Macronix 29F002T-90 is a suitable choice for embedded systems, industrial control systems, networking devices, and consumer electronics.
