MA4P7436-1141T M/A-Com Technology Solutions MA4P7436-1141T label picture
Same model may have multiple batches, images only for reference.
MA4P7436-1141T M/A-Com Technology Solutions MA4P7436-1141T label picture
MA4P7436-1141T M/A-Com Technology Solutions MA4P7436-1141T label picture
Same model may have multiple batches, images only for reference.

MA4P7436-1141T

Part No MA4P7436-1141T
Manufacturer M/A-Com Technology Solutions
Catalog RF Diodes
Description DIODE,PIN,PLASTIC,LEADFREE
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - RF Diodes
Mfr M/A-Com Technology Solutions
Series SMPP
Package Tape & Reel
Product Status Active
Diode Type PIN - Single
Voltage - Peak Reverse (Max) 75V
Current - Max 150 mA
Capacitance @ Vr, F 1pF @ 20V, 1MHz
Resistance @ If, F 500mOhm @ 10mA, 100MHz
Power Dissipation (Max) 200 mW
Temperature Range - Operating 175°C (TJ)
Package / Case SC-76, SOD-323
Supplier Device Package SOD-323
Base Product Number MA4P7436
Standard Package 3,000 pcs
Moisture Sensitivity Level (MSL) 3 (168 Hours)
ECCN EAR99
HTSUS 8541.10.0060
Win Source Part Number 206777-MA4P7436-1141T
Ultra Librarian 3D Model Ultra Librarian MA4P7436-1141T CAD Model

Description

The RF Diode with Win Source Part Number 206777-MA4P7436-1141T is a high-quality discrete semiconductor product designed for RF applications.

  • Series: SMPP
  • Maximum Current: 150mA
  • Voltage Peak Reverse: 75V
  • Capacitance: 1pF @ 20V and 1MHz
  • Package: SC-76, SOD-323 package
  • Brand: M/A-Com Technology Solutions
  • Status: Active
