KSDB324N Littelfuse Inc. – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

KSDB324N

Part No KSDB324N
Manufacturer Littelfuse Inc.
Catalog Time Delay Relays
Description RELAY TIME DELAY 100MIN CHAS MT
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Mounting Type Chassis Mount
Relay Type Solid State Relay
Function Off-Delay
Circuit SPST-NO (1 Form A)
Delay Time 1 Min ~ 100 Min
Voltage - Supply 24VDC
Termination Style Quick Connect - 0.250" (6.3mm)
Timing Adjustment Method External Resistor
Timing Initiate Method Input Voltage, Trigger Signal
Package Bulk
Supply and Demand Status Shortage
Win Source Part Number 1508506-KSDB324N
Ultra Librarian 3D Model Ultra Librarian KSDB324N CAD Model

Description

N
