JLLS175.X Real Image
Same model may have multiple batches, images only for reference.

JLLS175.X

Part No JLLS175.X
Manufacturer Littelfuse Inc.
Catalog Electrical, Specialty Fuses
Description FUSE CRTRDGE 175A 600VAC/300VDC / Fuse Class T Fast Acting 175A 600V Bolt Plug 42.1 X 27mm CSA/UL
Datasheet
JLLS175.X Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Circuit Protection
Manufacturer Littelfuse Inc.
Series POWR-GARD JLLS
Packaging Bulk
Fuse Type Cartridge
Current Rating 175A
Voltage Rating - AC 600V
Voltage Rating - DC 300V
Response Time Fast
Applications Electrical, Industrial
Class T
Approvals CE, CSA, UL
Breaking Capacity @ Rated Voltage 200kA
Mounting Bolt Mount
Package Cylindrical, Blade Terminal (Bolt)
Dimension 1.063" Dia x 1.657" L (27.00mm x 42.10mm)
Win Source Part Number 780090-JLLS175.X
Popularity Medium
Supply and Demand Status Balance
Family Name JLLS
Introduction Date January 16, 2004
ECCN EAR99
Country of Origin Mexico
Estimated EOL Date 2025
Ultra Librarian 3D Model Ultra Librarian JLLS175.X CAD Model

Description

The Littelfuse Inc. JLLS175.X is a cartridge fuse.

  • Current Rating: 175A
  • Voltage Rating: 600V AC, 300V DC
  • Breaking Capacity @ Rated Voltage: 200kA
  • Operating Temperature: -40°C ~ 110°C
  • Dimension: 1.063" Dia x 1.657" L (27.00mm x 42.10mm)
  • Popularity: 49 pct
  • Supply and Demand Status: Balance
  • Estimated EOL Date: 2025
