ANT-916-SP Real Image
Same model may have multiple batches, images only for reference.

ANT-916-SP

Part No ANT-916-SP
Manufacturer Linx Technologies Inc.
Catalog RF Antennas
Description RF ANT 916MHZ CHIP SOLDER SMD / 915MHz ISM, LoRa, Sensor Networks, SigFox Chip RF Antenna 900MHz ~ 930MHz 1.4dBi Solder Surface Mount
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category RF/IF and RFID>RF Antennas
Mfr Linx Technologies Inc.
Series Splatch®
Package Tube
RF Family/Standard General ISM
Frequency Group UHF (300MHz ~ 1GHz)
Frequency (Center/Band) 915MHz
Frequency Range 900MHz ~ 930MHz
Antenna Type Chip
Number of Bands 1
VSWR 1.9
Gain 1.4dBi
Termination Solder
Mounting SMD (SMT)
Height (Max) 0.059" (1.50mm)
Applications ISM, LoRa, Sensor Networks, SigFox
Base Product Number ANT-916
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8529.10.4040
Other Names ANT-916-SP_,ANT916SP,Q9220103A,ANT-916-SP_-ND
Standard Package 20
Win Source Part Number 1041609-ANT-916-SP
Ultra Librarian 3D Model Ultra Librarian ANT-916-SP CAD Model

Description

The Linx Technologies Inc. 1041609-ANT-916-SP is a Splatch® chip antenna that operates in the frequency range of 900MHz to 930MHz.

  • Frequency Range: 900MHz to 930MHz
  • Applications: ISM, LoRa, Sensor Networks, and SigFox
  • Gain: 1.4dBi
  • VSWR: 1.9
  • Antenna Type: Chip
  • Number of Bands: 1
  • Mounting: SMD (SMT)
  • Termination: Solder
  • Frequency Group: UHF (300MHz ~ 1GHz)
  • Frequency (center/band): 915MHz
  • MSL Level: 1 (Unlimited)
  • REACH Status: REACH unaffected
  • HTSUS: 8529.10.4040
  • Other Names: ANT-916-SP_, ANT916SP, Q9220103A, and ANT-916-SP_-ND
