LTC6993IS6-1#TRMPBF TimerBlox: Voltage-Controlled Pulse Width Modulator

The LTC6993IS6-1#TRMPBF is a highly versatile and innovative component from Linear Technology, designed to serve as a voltage-controlled pulse width modulator within the TimerBlox® series. This integrated circuit (IC) offers precision timing capabilities, making it an ideal choice for a wide range of applications that require reliable and adjustable pulse generation.

Key Features

• Adjustable Pulse Width Modulation: The LTC6993IS6-1#TRMPBF allows users to adjust the duty cycle of the output pulse from 0% to 100% using a single external resistor or a voltage-controlled input.
• Frequency Range: The device can operate over a frequency range of 3.81Hz to 1MHz, providing flexibility for various timing requirements.
• Low Power Consumption: With its power-saving features, the LTC6993IS6-1#TRMPBF is an excellent choice for battery-powered devices and portable applications.
• CMOS Output Driver: The IC includes a CMOS output driver capable of sourcing or sinking up to 20mA, allowing it to directly drive a load or interface with other digital components.
• Wide Supply Voltage Range: It operates over a supply voltage range of 2.25V to 5.5V, accommodating various power supply configurations.
• Temperature Range: The device is designed to function in a wide temperature range from -40°C to 125°C, ensuring reliable operation in extreme conditions.

Applications

The LTC6993IS6-1#TRMPBF is suitable for a multitude of applications, including but not limited to:

• Precision pulse generation
• Frequency discrimination
• Time delay generation
• Pulse position modulation
• Complex waveform generation

Package and Reliability

Encased in a compact SOT-23 package, the LTC6993IS6-1#TRMPBF is designed for space-constrained applications. It is also available in a tape and reel format under the part number LTC6993IS6-1#TRMPBF, facilitating automated assembly processes. The robust design and manufacturing process ensure high reliability, making it a trusted choice for both industrial and commercial products.

Overall, the LTC6993IS6-1#TRMPBF from Linear Technology is a sophisticated and reliable solution for designers seeking a high-performance, adjustable pulse width modulator for their electronic designs.
