Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Linear Technology
Packaging Reel - TR
Status Active
Type Oscillator, Silicon
Frequency 80MHz
Supply Voltage - Operating 2.7 V to 5.5 V
Operating Supply Current 7mA
Temperature Range - Operating -40°C to 85°C
Case / Package TSOT-23-5
Mounting Surface Mount
Win Source Part Number 141172-LTC6905CS5-80#TRPBF
Ultra Librarian 3D Model Ultra Librarian LTC6905CS5-80#TRPBF CAD Model

Description

The LTC6905CS5-80#TRPBF is a high-performance, precision silicon oscillator manufactured by Linear Technology, a renowned leader in the design and production of high-performance analog integrated circuits. This compact and robust device offers a fixed frequency of 80MHz and is designed for applications that require a stable and reliable clock signal without the need for external tuning components.

Key Features

  • Fixed Frequency: The device provides a stable 80MHz clock signal, which is ideal for various digital applications.
  • High Accuracy: It delivers a precision frequency with low jitter, ensuring that your application runs smoothly and reliably.
  • Low Power Consumption: Designed for efficiency, the LTC6905CS5-80#TRPBF maintains low power usage, making it suitable for battery-powered devices.
  • Compact Size: Housed in a small SOT-23 package, this oscillator saves valuable board space and is ideal for space-constrained applications.
  • Temperature Stability: The device operates consistently across a wide temperature range, ensuring performance is maintained in various environments.
  • Supply Voltage Range: It can be powered by a supply voltage in the range of 2.7V to 5.5V, providing flexibility in different system designs.

Applications

The LTC6905CS5-80#TRPBF is versatile and can be used in a multitude of electronic applications, including:

  • Portable and wireless devices
  • Networking equipment such as routers and switches
  • Computing peripherals
  • Consumer electronics
  • Industrial and automotive systems

Quality and Reliability

Linear Technology ensures that the LTC6905CS5-80#TRPBF meets rigorous standards for quality and reliability. The device is available in a RoHS-compliant, lead-free finish and is designed to withstand the demands of modern electronic applications. The LTC6905CS5-80#TRPBF is a testament to Linear Technology's commitment to providing high-quality, reliable components for the electronics industry.
