LTC6902CMS#PBF - Programmable Oscillator
The LTC6902CMS#PBF is a versatile Silicon Oscillator manufactured by Linear Technology, now part of Analog Devices, designed to provide a high-performance clock generation solution. This compact, precision, programmable oscillator is suitable for a wide range of applications including portable devices, communication systems, and embedded systems where space and power are at a premium.
Key Features
- Frequency Range: The LTC6902 offers a wide frequency range from 1kHz to 68MHz, which can be programmed using an external resistive divider or serial interface.
- Multiple Output Types: It provides both CMOS and differential outputs, allowing it to interface with a variety of digital circuits.
- Low Power Consumption: The device is optimized for low power consumption, which is critical for battery-powered applications.
- Spread Spectrum Frequency Modulation: The LTC6902 includes spread spectrum frequency modulation capability, which can be used to reduce electromagnetic interference (EMI).
- No External Components Required: It operates without the need for external components such as resistors, capacitors, or inductors, simplifying design and reducing board space.
Applications
- Wireless Communications
- Portable Instruments
- Medical Devices
- Automotive Systems
- Networking Equipment
Product Specifications
Parameter
Value
Package
10-lead MSOP
Temperature Range
-40°C to 85°C
Supply Voltage
2.7V to 5.5V
The LTC6902CMS#PBF is a highly flexible solution for generating programmable frequencies with precision. Its low power consumption and small form factor make it an ideal choice for a myriad of modern electronic applications where reliable clock sources are needed.
