The LTC4265IDE#PBF is a sophisticated hot swap controller designed by Linear Technology to provide safe board insertion and removal from a live backplane. This integrated circuit allows a board to be safely inserted and removed from a live Power over Ethernet (PoE) system by controlling the inrush current to prevent glitches on the supply rail and damage to the connector contacts and system components.

Key Features

• Integrated Hot Swap Controller: Ensures safe insertion and removal of electronic boards from a live power source, protecting both the device and the power system from surges and inrush currents.
• Advanced Power Monitoring: Features precise monitoring of input voltage, current, and power use for enhanced control and protection of the system.
• High Voltage Capability: Supports applications with operating voltages up to 80V, making it suitable for a wide range of industrial and telecommunications applications.
• IEEE 802.3af Compliant: Fully compliant with the IEEE 802.3af PoE standard, ensuring compatibility with other PoE devices and systems.
• Compact Package: The LTC4265IDE#PBF comes in a small 14-lead DE package, ideal for space-constrained applications.
• Adjustable Current Limit: Offers an adjustable current limit threshold via an external resistor, providing flexibility to match the requirements of various applications.

Applications

This device is particularly useful in network equipment such as switches, routers, and base stations where PoE is utilized. It is also well-suited for industrial applications, remote sensors, and any other systems that benefit from hot-swap capability and power monitoring.

Product Quality and Reliability

Linear Technology ensures that the LTC4265IDE#PBF meets the highest standards of quality and reliability, providing a robust solution for critical applications where uptime and system integrity are paramount.
