Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Linear Technology
Packaging Reel - TR
Status Active
Type Hot Swap Controller
Number of Channels 1
Applications General Purpose
Features Auto Retry
Programmable Features Current Limit, Fault Timeout, OVP, Slew Rate, UVLO
Supply Voltage - Operating 2.7 V to 16.5 V
Temperature Range - Operating 0°C to 70°C
Operating Supply Current 650μA
Mounting SMD (SMT)
Case / Package TSOT-23-6
Feature Pins ON, TIMER
Win Source Part Number 303447-LTC4210-1CS6#TR
Ultra Librarian 3D Model Ultra Librarian LTC4210-1CS6#TR CAD Model

Description

LTC4210-1CS6#TR Hot Swap Controller

The LTC4210-1CS6#TR from Linear Technology is a cutting-edge hot swap controller designed to enable safe board insertion and removal from a live backplane. This compact, high-performance integrated circuit (IC) provides robust protection and precise control for power supply connections, ensuring that electronic devices operate reliably and efficiently.

Key Features

  • Soft-Start Capability: The LTC4210-1CS6#TR integrates a soft-start feature that controls the inrush current during the initial power-up phase, thereby preventing damage to the connectors, backplane, and power supply components.
  • Overcurrent Protection: This device offers fast response to overcurrent conditions, protecting the system from potential harm due to excessive power draw or short circuit events.
  • High-Side Drive: The controller operates as a high-side drive, which allows for the control of the supply voltage to the load without the need for a ground return path, enhancing system reliability.
  • Adjustable Current Limit: Users can set the current limit threshold to match the requirements of their specific application, ensuring tailored protection and performance.
  • Compact Size: Housed in a small 6-pin SOT-23 package, the LTC4210-1CS6#TR is ideal for space-constrained applications, providing powerful control in a minimal footprint.
  • Under-Voltage Lockout: The inclusion of an under-voltage lockout function ensures that the device operates only when the input voltage is within a safe range, thus safeguarding the system components.

Applications

With its robust feature set, the LTC4210-1CS6#TR is particularly well-suited for a range of applications where power management and protection are critical. These include:

  • Servers and data centers
  • Network routers and switches
  • Base stations
  • Industrial systems
  • RAID systems

The LTC4210-1CS6#TR hot swap controller from Linear Technology is an essential component for designers who need to ensure the safety and integrity of their high-availability systems. Its advanced protection features, combined with its ease of integration, make it an excellent choice for managing power distribution in sophisticated electronic systems.
