Products specifications

Categories RF/IF and RFID
Manufacturer Linear Technology
Packaging Reel - TR
Status Active
Frequency 10MHz to 6GHz
RF Type CATV
Input Range -34dBm to 6dBm
Accuracy ±1dB
Supply Voltage - Operating 2.7 V to 5.25 V
Operating Supply Current 1.4mA
Case / Package 8-DFN (3x2)
Win Source Part Number 95163-LT5581IDDB
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian LT5581IDDB CAD Model

Description

The LT5581IDDB is a high-precision RF power detector from Linear Technology, designed to provide accurate power measurement across a wide frequency range. This device is ideal for applications such as cellular base stations, RF test equipment, and wireless infrastructure, where precise power control and monitoring are critical for optimal performance.

Key Features:

  • Frequency Range: The LT5581IDDB offers a broad frequency range from 10MHz to 6GHz, making it versatile for a wide array of RF applications.
  • Dynamic Range: It boasts a dynamic range of 40dB, ensuring reliable detection from low-power signals to high-power signals without the need for external attenuation.
  • Temperature Stability: The device is designed with excellent temperature stability, maintaining consistent performance over varying environmental conditions.
  • Logarithmic Linearity: Ensuring high accuracy, the LT5581IDDB provides a logarithmic response that is proportional to the RF input power, delivering a linear-in-dB output voltage.
  • Fast Response Time: With a fast response time, this power detector quickly adapts to changes in signal power, which is essential for real-time monitoring and control applications.
  • Low Supply Voltage: Operating with a single supply voltage ranging from 3.3V to 5.25V, the LT5581IDDB is compatible with a variety of system power rails.
  • Compact Package: Housed in a small 8-lead DFN package, the LT5581IDDB saves valuable board space in space-constrained designs.

Applications:

  • Cellular Base Stations
  • RF Power Amplifier Linearization
  • Transmitter Power Control
  • Wireless Infrastructure
  • RF Test Equipment

The LT5581IDDB RF power detector embodies Linear Technology's commitment to high-performance, robust, and reliable RF solutions. Its integration into your design ensures precise power measurements and contributes to the efficiency and accuracy of your RF systems.
