Products specifications Report Issue?

Categories Circuit Protection
Manufacturer Linear Technology
Packaging Reel - TR
Status Active
Voltage - Clamping 27V Adj
Technology External Switch
Number of Circuits 1
Applications Automotive
Mounting SMD (SMT)
Case / Package 10-MSOP
Voltage - Working 4 to 80V
Win Source Part Number 1059875-LT4356IMS-1#TRPBF
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian LT4356IMS-1#TRPBF CAD Model

Description

The LT4356IMS-1#TRPBF from Linear Technology is a robust surge stopper device designed to protect sensitive electronics against high voltage surges and temporary overvoltage conditions. This advanced component is essential for ensuring the longevity and reliability of electronic systems in harsh environments.

Key Features

  • Overvoltage Protection: The LT4356IMS-1#TRPBF is capable of controlling the gate of an external N-channel MOSFET to act as a variable resistor, clamping the output voltage at a safe level during an overvoltage event.
  • Wide Operating Range: It operates over a wide voltage range, making it suitable for a variety of applications, including automotive, industrial, and avionics systems.
  • Adjustable Overvoltage Lockout: The device features an adjustable overvoltage lockout set with a simple resistor divider, allowing precise control over the protection threshold.
  • Reverse Input Protection: It also offers reverse input protection to safeguard against negative supply voltages.
  • Indefinite Short-Circuit Protection: The LT4356 can withstand indefinite short-circuit conditions, ensuring that the device remains protected even during extreme fault scenarios.

Applications

The LT4356IMS-1#TRPBF is ideal for a range of applications where voltage surges can pose a risk to electronic components. It is commonly used in:

  • Automotive electronics
  • Industrial control systems
  • Avionics and aerospace systems
  • Power supplies and converters
  • Telecommunications equipment

Technical Specifications

With a temperature range from -40°C to +125°C and packaged in a compact 10-pin MSOP, the LT4356IMS-1#TRPBF is designed for easy integration into existing designs. It is available in tape and reel packaging, denoted by the #TRPBF suffix, for convenient automated assembly processes.

In summary, the LT4356IMS-1#TRPBF surge stopper from Linear Technology provides a reliable, adjustable, and high-performance solution for protecting sensitive electronics from voltage transients and surges. Its robust design and versatile features make it an essential component for any application requiring stringent voltage protection.
