LT1782CS5#TRPBF - Low Power, Rail-to-Rail Input and Output Precision Op Amp

The LT1782CS5#TRPBF is a high-performance operational amplifier (op amp) from Linear Technology, designed to offer precision with low power consumption. This operational amplifier is suitable for battery-powered applications and portable devices due to its low quiescent current and wide input and output voltage ranges.

Key Features:

• Rail-to-Rail Input and Output: The LT1782CS5#TRPBF can operate with inputs and outputs extending to both supply rails. This feature allows for maximum dynamic range in low voltage applications, making it an ideal choice for single supply operations.
• Low Power Consumption: With a supply current of just 20µA, this op amp is optimized for power-sensitive applications. It ensures efficient operation without sacrificing performance, making it well-suited for portable and battery-operated equipment.
• Precision Performance: The device boasts an offset voltage of only 375µV max, which contributes to its high accuracy. It is perfect for applications that require precise signal amplification or conditioning.
• Wide Supply Range: The LT1782CS5#TRPBF operates from a supply voltage range of 2.5V to 11V, accommodating various power supply configurations and ensuring compatibility with a broad range of other components.
• Extended Temperature Range: The operational amplifier is designed to work over an industrial temperature range from -40°C to 85°C, ensuring reliable performance in harsh environments.
• Compact Package: Available in a tiny 5-lead SOT-23 package, the LT1782CS5#TRPBF saves board space and is ideal for space-constrained applications.

Applications:

The LT1782CS5#TRPBF is versatile and can be used in a variety of applications, including:

• Portable Medical Devices
• Battery-Powered Instruments
• Sensor Amplifiers
• Low Voltage Data Acquisition Systems
• Active Filters
• Notebook and PDA Power Management

With its combination of precision, low power, and rail-to-rail input/output capabilities, the LT1782CS5#TRPBF from Linear Technology stands out as a robust solution for designers looking to optimize their systems for both performance and power efficiency.
