LT1016IS8#TRPBF

Part No LT1016IS8#TRPBF
Manufacturer Linear Technology
Catalog Linear - Comparators
Description IC COMPARATOR 10NS HI-SPD 8-SOIC
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Linear Technology
Packaging Reel - TR
Status Active
Type with Latch
Number of Elements 1
Output Type CMOS, Complementary, TTL
Voltage - Input Offset (Max) 3mV @ ±5V
Current - Input Bias (Max) 10μA @ ±5V
Current - Output (Typ) 20mA
Current - Quiescent (Max) 35mA
CMRR, PSRR (Typ) 96dB CMRR, 75dB PSRR
Propagation Delay (Max) 14ns
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 8-SOIC
Win Source Part Number 112927-LT1016IS8#TRPBF
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian LT1016IS8#TRPBF CAD Model

Description

The LT1016IS8#TRPBF is a leading-edge precision comparator from Linear Technology, renowned for its ultra-fast response time and high accuracy. This high-speed comparator is designed to provide rapid and precise voltage level detection, making it an ideal choice for a wide range of applications, including zero-crossing detectors, high-speed triggers, and pulse and square-wave shapers.

Key Features:

  • Ultra-Fast Propagation Delay: With a typical propagation delay of just 10ns, the LT1016 ensures quick response times, which is crucial for high-speed signal processing applications.
  • Strobe Capability: The inclusion of a strobe pin allows users to gate the comparator's output, providing additional control over the timing of the output signal.
  • Low Power Consumption: Despite its high-speed operation, the LT1016IS8#TRPBF maintains low power consumption, making it suitable for power-sensitive designs.
  • Overdrive Protection: The comparator is designed to handle input overdrive conditions, ensuring reliable performance and longevity of the device.
  • Output Latch Function: The device features an output latch function that can hold the output state, which is useful for implementing memory and decision-making functions in digital systems.

Specifications:

  • Package: The device is available in an 8-lead SOIC package, which is compact and suitable for space-constrained applications.
  • Temperature Range: It operates over an industrial temperature range, making it robust for use in challenging environmental conditions.
  • Supply Voltage: The LT1016 can be powered by a single 5V supply or dual supplies ranging from ±1V to ±18V, providing flexibility in various circuit designs.

Applications:

The LT1016IS8#TRPBF is versatile and can be used in a multitude of applications. Its precision and speed are particularly beneficial in data acquisition systems, high-speed instrumentation, and automated test equipment. Additionally, its robust design makes it suitable for industrial control systems, communication systems, and any other application that requires a fast and accurate voltage comparison.

With its exceptional performance and reliability, the LT1016IS8#TRPBF is a top choice for engineers and designers looking to enhance the speed and precision of their electronic systems.
