GAL22V10D-10QJ Lattice Semiconductor Corporation GAL22V10D-10QJ real image
Same model may have multiple batches, images only for reference.
GAL22V10D-10QJ Lattice Semiconductor Corporation GAL22V10D-10QJ real image
GAL22V10D-10QJ Lattice Semiconductor Corporation GAL22V10D-10QJ real image
Same model may have multiple batches, images only for reference.

GAL22V10D-10QJ

Part No GAL22V10D-10QJ
Manufacturer Lattice Semiconductor Corporation
Catalog Embedded - CPLDs (Complex Programmable Logic Devices)
Description High Performance E2CMOS PLD Generic Array Logic | IC CPLD 10MC 10NS 28PLCC
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Lattice Semiconductor Corporation
Packaging Bulk
Status Obsolete
Programmable Type EE PLD
Delay Time tpd(1) Max 10.0ns
Voltage Supply - Internal 4.75V ~ 5.25V
Number of Macrocells 10
Temperature Range - Operating 0°C ~ 75°C
Mounting Style SMD
Manufacturer Package 28-LCC
Supplier Device Package 28-PLCC (11.51x11.51)
Family Part Number GAL22V10
Manufacturer Pack Quantity 370
MSL Level 3 (168 Hours)
Win Source Part Number 1176837-GAL22V10D-10QJ
Manufacturer Homepage www.latticesemi.com
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian GAL22V10D-10QJ CAD Model

Description

The GAL22V10D-10QJ is an obsolete programmable logic device manufactured by Lattice Semiconductor Corporation.

  • Supply and Demand Status: Limited
  • RoHS Compliant: Yes
  • Manufacturer Homepage: www.latticesemi.com
  • Delay Time tpd(1) max: 10.0ns
  • Voltage Supply: 4.75V ~ 5.25V
  • Macrocells: 10
  • Suitable for: Use in various electronic devices
