GAL22V10D-15LP Lattice Semiconductor Corporation
Same model may have multiple batches, images only for reference.

GAL22V10D-15LP

Part No GAL22V10D-15LP
Manufacturer Lattice Semiconductor Corporation
Catalog Embedded - CPLDs (Complex Programmable Logic Devices)
Description High Performance E2CMOS PLD Generic Array Logic | IC CPLD 10MC 15NS 24DIP
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Lattice Semiconductor Corporation
Packaging Bulk
Status Obsolete
Programmable Type EE PLD
Delay Time tpd(1) Max 15.0ns
Voltage Supply - Internal 4.75V ~ 5.25V
Number of Macrocells 10
Temperature Range - Operating 0°C ~ 75°C
Mounting Style Through Hole
Manufacturer Package 24-DIP
Supplier Device Package 24-PDIP
Family Part Number GAL22V10
Manufacturer Pack Quantity 300
MSL Level 3 (168 Hours)
Win Source Part Number 1176842-GAL22V10D-15LP
Manufacturer Homepage www.latticesemi.com
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian GAL22V10D-15LP CAD Model

Description

The GAL22V10D-15LP is an obsolete integrated circuit manufactured by Lattice Semiconductor Corporation.

  • Package: 24-PDIP
  • Packaging: bulk
  • Type: EE PLD programmable device
  • Delay time tpd(1) Max: 15.0ns
  • Internal voltage supply: 4.75V ~ 5.25V
  • Macrocells: 10
  • Market concern: threatened by fake products
  • Supply and demand status: balanced
  • Applications: automation and process control, sensing and instrumentation, and portable devices.
