The Kemet T520M157M006AE200 is a high-performance solid electrolytic capacitor designed for demanding applications requiring exceptional stability and reliability. It is part of Kemet’s T520 series, known for its Polymer Hermetic Molded Chip capacitors, which offer very low ESR (Equivalent Series Resistance) and high ripple current capabilities.

Applications

• DC-DC Converters
• Power Management Circuits
• High Ripple Current Applications
• Filtering in Power Supplies
• Buffering in High-Speed Digital Circuits

Features

• Capacitance: 150µF
• Voltage Rating: 6.3V
• ESR (Equivalent Series Resistance): 200 mΩ
• Tolerance: ±20%
• Operating Temperature Range: -55°C to +125°C
• Case Size: Same as EIA 7343-20
• Termination: Standard Termination
• RoHS Compliant

Benefits

• Low ESR: Minimizes power loss and heat generation, improving efficiency in power applications.
• High Ripple Current Capability: Ensures stable performance under high current conditions, extending the lifespan of the capacitor.
• Stable Performance: Polymer cathode provides excellent capacitance retention and stability across a wide temperature range.
• Long Lifespan: Robust design and materials contribute to a long operational life, reducing the need for frequent replacements.
• Compact Size: Efficient use of board space due to the capacitor's molded chip design.

Additional Details

The T520 series utilizes a conductive polymer cathode, offering significant advantages over traditional MnO2 capacitors, particularly in ESR and voltage derating characteristics. The 150µF capacitance provides effective filtering and energy storage. The 6.3V voltage rating suits many low-voltage power systems. The T520M157M006AE200’s low ESR of 200 mΩ minimizes losses and heat, ensuring reliable operation in demanding circuits. This capacitor is designed for surface mount technology (SMT) and adheres to industry-standard dimensions for easy integration into automated assembly processes.

The device’s high operating temperature range of -55°C to +125°C allows it to be used in harsh environments. The Polymer Hermetic Molded Chip construction provides enhanced protection against moisture and other environmental factors, further improving reliability. The T520M157M006AE200 is ideal for applications requiring high performance, stability, and longevity in a compact form factor.
