Same model may have multiple batches, images only for reference.
SC-11-20J Real Image
Same model may have multiple batches, images only for reference.

SC-11-20J

Part No SC-11-20J
Manufacturer Kemet
Catalog Common Mode Chokes
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Filters>Common Mode Chokes
Mfr KEMET
Series SC
Package Tray
Filter Type Power Line
Number of Lines 2
Inductance @ Frequency 2 mH @ 10 kHz
Current Rating (Max) 11A
DC Resistance (DCR) (Max) 14mOhm
Voltage Rating - DC 250V
Voltage Rating - AC 250V
Temperature Range - Operating 25°C ~ 120°C
Mounting Type Through Hole
Dimension 1.378" L x 0.906" W (35.00mm x 23.00mm)
Height (Max) 1.299" (33.00mm)
Package / Case Vertical, 4 PC Pin
Base Product Number SC-11
Other Names 399-SC-11-20J,UALSC1120J0000
Standard Package 200
MSL Level Not Applicable
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.8000
Win Source Part Number 1276990-SC-11-20J
Ultra Librarian 3D Model Ultra Librarian SC-11-20J CAD Model

Description

The KEMET 1276990-SC-11-20J is a common mode choke filter with a voltage rating of 250V and a current rating of 11A.

  • Filter Type: Power line
  • Lines: Two lines
  • Inductance: 2 mH @ 10 kHz
  • DC Resistance: 14mOhm
  • Mounting: Through hole
  • Package/Case: Vertical, 4 PC pin
  • Temperature Range: 25°C to 120°C
  • Dimension: 1.378" L x 0.906" W (35.00mm x 23.00mm)
  • ECCN: EAR99
  • REACH: Unaffected
