EA2-12NU Kemet EA2-12NU Real Image EA2-12NU Real Image
Same model may have multiple batches, images only for reference.
EA2-12NU Kemet EA2-12NU Real Image EA2-12NU Real Image
EA2-12NU Kemet EA2-12NU Real Image EA2-12NU Real Image
Same model may have multiple batches, images only for reference.

EA2-12NU

Part No EA2-12NU
Manufacturer Kemet
Catalog Signal Relays, Up to 2 Amps
Description RELAY GEN PURPOSE DPDT 1A 12V
Datasheet
EA2-12NU Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Relays
Manufacturer Kemet
Packaging Tube/Rail
Status Active
Relay Type General Purpose
Coil Type Non Latching
Coil Current 11.7mA
Coil Voltage 12VDC
Contact Form DPDT (2 Form C)
Contact Rating (Current) 1A
Switching Voltage 250VAC, 220VDC - Max
Turn On Voltage (Max) 9 VDC
Turn Off Voltage (Min) 1.2 VDC
Operate Time 2ms
Release Time 1ms
Mounting Through Hole
Termination Style PC Pin
Coil Power 140 mW
Coil Resistance 1.03 kOhms
Temperature Range - Operating -40°C to 85°C
Win Source Part Number 1035746-EA2-12NU
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian EA2-12NU CAD Model

Description

The EA2-12NU is a general-purpose relay type of electronic component manufactured by Kemet.

  • Packaging: Tube/Rail
  • Termination Style: PC Pin
  • Mounting Type: Through Hole
  • Contact Form: DPDT (2 Form C)
  • Coil Resistance: 1.03 kOhms
  • Coil Current: 11.7mA
  • Operate Time: 2ms
  • Coil Type: Non-Latching
  • Coil Voltage: 12VDC
  • Contact Rating Current: 1A
  • Switching Voltage: 250VAC, 220VDC - Max
  • Turn On Voltage (Max): 9VDC
  • Turn Off Voltage (Min): 1.2VDC
  • Release Time: 1ms
  • Coil Power: 140mW
  • Category: Relays
  • Popularity: Medium
  • Temperature Range: -40°C to 85°C
