FI-S3P-HFE-E1500 JAE Electronics
Same model may have multiple batches, images only for reference.

FI-S3P-HFE-E1500

Part No FI-S3P-HFE-E1500
Manufacturer JAE Electronics
Catalog Rectangular Connectors
Description CONN HEADER SMD R/A 3POS 1.25MM
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer JAE Electronics
Packaging Reel
Connector Type Receptacle
Contact Type Male Pin
Pitch - Mating 0.049"
Number of Positions 3
Number of Rows 1
Number of Positions Loaded All
Style Board to Cable/Wire
Shrouding Shrouded - 4 Wall
Mounting Style Surface Mount, Right Angle
Termination Solder
Fastening Type Friction Lock
Insulation Height 0.071" (1.80mm)
Contact Shape Square
Contact Finish - Mating Gold
Contact Finish - Post Tin or Tin-Alloy
Contact Material Copper Alloy
Insulation Material Liquid Crystal Polymer (LCP), Glass Filled
Features Solder Retention
Temperature Range - Operating -40°C ~ 80°C
Material Flammability Rating UL94 V-0
Insulation Color Beige
Current Rating (Amps) 1A per Contact
Voltage Rating 200V
Manufacturer Pack Quantity 1,500
MSL Level 1 (Unlimited)
Popularity Medium
Supply and Demand Status Balance
Win Source Part Number 808180-FI-S3P-HFE-E1500
Ultra Librarian 3D Model Ultra Librarian FI-S3P-HFE-E1500 CAD Model

Description

The receptacle connector JAE Electronics 808180-FI-S3P-HFE-E1500 is designed for use in connectors from JAE Electronics.

  • Positions: 3
  • Mounting Type: Surface Mount, Right Angle
  • Fastening: Solder Retention
  • Contact Material: Copper Alloy
  • Insulation Material: Liquid Crystal Polymer (LCP), Glass Filled
  • Voltage Rating: 200V
  • Flammability Rating: UL94 V-0
  • Shrouding: 4 Walls
  • Pitch: 0.049"
  • Contact Finish (Mating): Gold
  • Contact Finish (Post): Tin or Tin-alloy
  • Insulation Height: 0.071" (1.80mm)
  • Contact Shape: Square
  • Operating Temperature: -40°C ~ 80°C
  • Manufacturer Pack Quantity: 1,500
  • MSL Level: 1 (Unlimited)
  • Current Rating: 1A per contact
