Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer IXYS
Packaging Tube
Status Obsolete
Transistor Polarity N-Channel
Technology MOSFET
Vds - Drain-Source Breakdown Voltage 500V
Id - Continuous Drain Current 20A
Drive Voltage (Max Rds On, Min Rds On) 10V
Rds On (Maximum) at Id, Vgs 270mOhm at 12A, 10V
Gate Source Voltage(th) (Maximum) at Id 4V at 250μA
Gate Charge (Qg) (Maximum) at Vgs 210nC at 10V
Gate Source Voltage (Maximum) ±20V
Input Capacitance (Ciss) (Maximum) at Vds 4200pF at 25V
Power Dissipation (Maximum) 260W
Temperature Range - Operating -55°C ~ 150°C
Mounting Style Through Hole
Supplier Device Package TO-247AD
Manufacturer Package TO-3P-3 Full Pack
Manufacturer Pack Quantity 30
MSL Level Not Applicable
Win Source Part Number 1187803-IRFP460
Manufacturer Homepage www.nxp.com
Popularity Medium
Supply and Demand Status Balance
Application Field Used in Power Management
Ultra Librarian 3D Model Ultra Librarian IRFP460 CAD Model

Description

The IXYS IRFP460 is an N-channel MOSFET that has a drain-source breakdown voltage of 500V and a continuous drain current of 20A.

  • Drain-Source Breakdown Voltage: 500V
  • Continuous Drain Current: 20A
  • Maximum Power Dissipation: 260W
  • Package: TO-247AD
  • Supply and Demand Status: Balanced
  • Manufacturer Pack Quantity: 30
