ISP825X-3 Isocom Components 2004 LTD
Same model may have multiple batches, images only for reference.

ISP825X-3

Part No ISP825X-3
Manufacturer Isocom Components 2004 LTD
Catalog Misc Products
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Uncategorized
Manufacturer Isocom Components 2004 LTD
Popularity Medium
Supply and Demand Status Limited
Win Source Part Number 826297-ISP825X-3
Package Tube
Product Status Active
Number of Channels 2
Voltage - Isolation 5300Vrms
Current Transfer Ratio (Min) 600% @ 1mA
Current Transfer Ratio (Max) 7500% @ 1mA
Rise / Fall Time (Typ) 60µs, 53µs
Input Type DC
Output Type Darlington
Voltage - Output (Max) 35V
Current - Output / Channel 80mA
Voltage - Forward (Vf) (Typ) 1.2V
Current - DC Forward (If) (Max) 50mA
Vce Saturation (Max) 1V
Grade -
Operating Temperature -30°C ~ 100°C
Mounting Type Through Hole
Package / Case 8-DIP (0.300", 7.62mm)
Supplier Device Package 8-DIP
Ultra Librarian 3D Model Ultra Librarian ISP825X-3 CAD Model

Description

The ISP825X-3 is an electronic component from Isocom Components 2004 LTD.

  • It is a medium-popularity product with limited supply and demand status.
  • Unfortunately, the product specification is not sufficient to provide a detailed description of the product.
  • However, based on our knowledge of electronic components, the ISP825X-3 is likely an optocoupler or an optoisolator with a transistor output.
  • It is designed to provide channel insulation and reliable performance in various applications.
  • For more information about the product, please contact Isocom Components 2004 LTD.
